Side Tilt Carriage - There are 4 sizings of hook type tine carriages rated by the blade carriage hoisting capability. Hook type tine carriages have been the same.
The carriage bar spacing for Class 1 is something like thirteen inches and the Class 1 carriage is rated to carry loads up to 2000lbs. The Class 2 carriage is rated to carry cargo up to 5,500lbs with carriage bar spacing of 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing utilized for this capacity is 25 inches.
The carriages for pin type blades could be different depending on the manufacturer. Pin mounted forks could differ by the amount of offset between the tine eye and the tine. Carriage capacity would be determined by the carriage pin size and by the tine size.
